180W LED Beam Wash Spot 3in1 Moving Head Light

The BK-BSW180 is a 180W LED moving head light that can be used as a spot light, wash light, or beam light.

It is highly versatile. It has a 10 colors with a rainbow effect.  13 gobos  with shaking and dual rotation, and 7 rotation gobo wheel for dynamic looks. And 4-facet rotating prism and frost effect add to its capabilities.

Brand
BKlite
Model No.
BK-BSW180
Power
230W
Light source
180W White LED
Input voltage
AC100V-240V 50-60Hz
Waterproof rating
IP20

Return Tips   After-Sales Service and Warranty:

We offer comprehensive after-sales services, including installation guidance and technical support. Our products also come with a specified warranty period to ensure a worry-free experience for our customers.

Buyer Protection   Buyer Protection: We Keep Buyer Information Completely Confidential!

INQUIRY

Key Features

• This versatility makes it a great choice for a variety of stage lighting applications, from concerts, stage, KTV, nightclubs,theaters etc..

Channel
Channels
18 DMX channel
Light source
Light source
180W White LED
Power
Power
230W
Mode
Mode
DMX512,RDM, Master/slave
Tilt
Scanning system
540° /270°

Excellent color mixing effect

180W 3in1 Renderings4
180W 3in1 Renderings1
180W 3in1 Renderings2
180W 3in1 Renderings3

Video

More parameters

Specification Details
Voltage AC100-240V 50-60Hz
Power 230W
LED Source 180W White LED
Zoom 11° - 27°
Strobe 0-25Hz
Control Mode DMX512, Sound-activated, Master/Slave
DMX Channels 18 DMX channel
Dimmer 0-100% linear dimmer with 4 dimmer curves
Pan/Tilt 540° + 16-bit fine/270° + 16-bit fine
Color wheel 10 Colors+open,with rainbow effect
Static Gobo Wheel 13 gobos+open,with shaking and bi-direction rotation
Rotation Gobo Wheel 7 gobos+open,gobo rotation and gobo effect
Prism 4facet round prism with bi-direction rotation
Frost with frost effect
Fixture Dimension 270*190*450mm
Net Weight (N.W.) 9.1kg
Product Details

Light source

•Light source:180W high brightness white LED

•Lighting color temperature:7500K

•Lighting luminous flux 14,000 lumens
•LED expected lifespan:50,000hour

Control and procedure

Four mechanical keys

Control protocol:DMX512,RDM

Display system:2.8 inch touch LCD screen, display in Chinese and English, 180 degree rotation

Colour and pattern

•Color wheel:10 color panels   white light, rainbow effect, can be positioned arbitrarily

•Rotation Gobo Wheell:7 gobos+open, gobo rotation and gobo

•static gobo wheel:13 gobos + open, with shaking and bi-direction

rotation

Other effects

•Dimmer: 0-100% smooth linear dimmer
•Strobe: 1-25 Hz with pulse effect
•Prism: 4 facet round prism with bi-direction rotation
•Frost: With frost effect

Work environment

•Maximum ambient temperature: 40°C
•Maximum surface temperature: 65°C
•Lowest working temperature: 0°C

Factory configuration

•Directions for use
•Power cord
•Signal cable
