Excellent color mixing effect
6PCS 60W RGBW 4in1 LED Infinite Bar Moving Head Light with Ring
With more than 14 years of experience in professional stage lighting, BKLITE is a specialized LED stage lighting manufacturer in China. The BKlite infinite bar moving‑head is an IP20 indoor fixture designed for concert tours, live rental shows, TV studios, nightclub productions and theatrical events. It has six independent 60W RGBW heads with infinite continuous rotation plus surrounding RGB ring lights, sculpting flying beam movements, swirling ring animations and multi‑layered dimensional stage visuals.
Brand
BKlite
Power
500W
Light source
6pcs 60w RGBW 4in1 LEDs, 6*24*0.3W RGB LEDs
Input voltage
AC 110-240V 50 / 60Hz
Waterproof rating
IP20
After-Sales Service and Warranty:
We offer comprehensive after-sales services, including installation guidance and technical support. Our products also come with a specified warranty period to ensure a worry-free experience for our customers.
Buyer Protection: We Keep Buyer Information Completely Confidential!
Key features
• Adopts dual-light source design (main beam + ambient glow): 6pcs 60W RGBW LEDs deliver high-brightness main light, while 144pcs circular RGB LEDs render atmosphere. Combined, they create layered 3D lighting effects with strong visual impact.
• It supports 360° unlimited continuous rotation horizontally/vertically, free from physical restrictions. It enables coherent and complex dynamic trajectories, offering high programming flexibility for seamless dynamic light shows.
• Supports pixel-level independent programming for each LED. It not only enables precise control of colors and patterns but also allows combining multiple fixtures to present grand dynamic graphics, flowing light walls, or custom animations and other advanced visual content on stage.
Channels
26CH/121CH /128CH
Light source
6x60W RGBW LEDs
Power
500W
Mode
DMX512,Auto, Master/slave, Sound
Video
More parameters
| Specification | Details |
| Voltage | AC100-240V 50-60Hz |
| Power | 500W |
| LED Source | 6x60W RGBW LEDs, Outer Circle: 6x24x0.3W RGB lamp beads |
| Strobe | 1-25Hz |
| Control Mode | DMX512, Sound-activated, Master/Slave |
| DMX Channels | 26CH/121CH /128CH |
| Dimmer | 0-100% linear dimmer |
| Pan | Unlimited rotation |
| Tilt | Unlimited rotation |
| IP Rate | IP20 |
| Fixture Dimension | 1260*130*300mm |
| Net Weight (N.W.) | 22KG |
Product Details
Control and procedure
•Five mechanical keys
•LCD display
•Upgrade files can be uploaded via the DMX interface
Installation
•Can be installed horizontally or vertically
•Universal operating position
•Foldable clamp at the bottom
•Safety rope connection hole
Factory configuration
•User manual
•Power cord
•Signal cable
•Safety rope
